4K 30fps PTZ IP Camera
A powerful and cost-effective HD and UltraHD PTZ camera with 30x zoom, 3G-SDI, HDMI and IP streaming.

Supports 4K UHD at 30fps and 1080P at 60fps
Powerful 30x optical zoom, with 68 degrees horizontal field of view at its widest setting
Easy installation: delivers video output via Ethernet, HDMI, and 3G-SDI simultaneously
Excellent support: 5 year warranty as standard

Supporting 4K and 1080p output, VC-A61P is future-proofed for all your production requirements for years to come. The CMOS sensor is partnered with a high brightness zoom lens which enables the camera to excel in virtually every lighting condition. It makes the VC-A61P a great PTZ choice, whether installed in a studio, theatre, conference center, or lecture hall.

The 30x lens is exceptionally powerful. It allows operators to zoom in close from the back of a venue or shoot wide to capture a full conference panel thanks to its 68 degree horizontal viewing angle. For extreme close shots, a digital zoom can be deployed, while 3D noise reduction maintains clear pictures and excellent results.

Equipped with HDMI, 3G-SDI, and Ethernet outputs, the VC-A61P can be integrated with almost any AV, broadcast or IP workflow. All models support simultaneous H.264 and HEVC streaming. Such a wide range of video outputs means that the camera is ready to fulfill a wide variety of roles - as a PTZ camera source for lecture capture, live event production, or video streaming direct to YouTube or Facebook.

*The VC-A61PN version of the camera adds NDI®|HX PTZ support for fast integration with NDI® infrastructures.

Lumens VC-A61P supports both PoE (Power over Ethernet) and a 12v DC input. It also features dedicated RS-232 in-out ports, RS-422, and Ethernet-based control protocol support (including Crestron, Extron, Visca, Pelco D, FreeD, and Onvif). This gives the camera an unparalleled level of flexibility: whatever the video workflow, whatever the AV integration, VC-A61P is ready to take the complexity out of camera installation and management.

5 Year Warranty

Sensor
1/2.5" 8.57MP CMOS

Video Format
2160p: 29.97 / 25
1080p: 59.94 / 50 / 29.97 / 25
1080i: 59.94 / 50
720p: 59.94 / 50 / 29.97 / 25

Video Output (HD) Interface
3G-SDI / HDMI / Ethernet

Optical Zoom
30x

Digital Zoom
12x

Horizontal Viewing Angle
68°

Vertical Viewing Angle
38.3°

Diagonal Viewing Angle
78°

Aperture
F1.6 ~ F3.4

Focal Length
4.6mm ~ 135mm

Shutter Speed
1/1 ~ 1/10,000 sec

Minimum Object Distance
1.5m (Wide/Tele)
Video S/N Ratio
> 50dB

Minimum Illumination
0.1 lux (F1.6, 50IRE, 30fps)

Focus System
Auto / Manual / Smart AF

Gain Control
Auto / Manual

White Balance
Auto / Manual

Exposure Control
Auto / Manual

WDR
Yes

3D NR
Yes

Image Flip
Yes

Tally Light
Yes

IP Protocol
RTSP / RTMP / RTMPS / MPEG-TS / SRT

PoE
PoE+ (IEEE802.3at)

HDMI / 3G-SDI
HDMI Output: 2160p29.97
3G-SDI Output: 1080p59.94

IP Stream
HEVC(H.265) 4K 29.97fps
H.264 1080p 59.94fps
H.264 640x360 29.97fps

IP Compression
HEVC(H.265) / H.264

Panning Angle
+170 ~ -170°

Panning Speed
300°/sec

Tilting Angle
+90 ~ -30°

Tilting Speed
300°/sec

Preset Positions
256

Audio Input
Line In / MIC In

Audio Output
Ethernet / SDI / HDMI

Audio Compression Format
G.711

Control Interface
RS-232 / RS-422 / Ethernet / Remote

Control Protocol
VISCA / VISCAIP / PELCO D / ONVIF

IR Pass-Through
Yes

IR Receiver
Yes

IR Remote Control
Yes

DC In
12V +/- 20%

Power Consumption
PoE: 18W
DC In: 16W

Weight
4.4 lbs (2 kg)

Dimensions
6.9" x 7.5" x 7.3"
(174 x 190 x 187 mm )

Package Contents
Instruction for installation
Remote Control
Power Cord
Power Adapter
RS-422 Connector
Metal Plate A
Metal Plate B
M3 Screws
