it is surprisingly powerful, capable of supporting up-to 7 PTZ cameras.
The unit can control cameras that conform to the VISCA and PELCO-D protocols and enables users to connect devices over long distances
via RS-232 or RS-422.
All key camera functions are at hand. Users have very fast access to camera presets, zoom angle, and multi-axis camera motion. Whether you’re looking for a portable unit, a device that can be operated with a minimum of training, or simply a cost-effective solution, VC-K20 is a great option. If you need an IP-based controller, check out Lumens VS-K20
Comm. Interface
Mini Din 8PIN
Protocol
VISCA
Baud Rate
9600/38400 bps
Camera Control (Max.)
7
Joystick
4-axis (Pan/Tilt/Zoom/Focus)
Display
OLED
Backlight
Auto / Manual
Power
DC12V
Power Consumption
< 2W
Dimensions (L x W x H)
200 x 120 x 103 mm (7.9” x 4.7” x 4.1”)
Weight
0.5 kg (1.1 lbs)
Package Contents
Power Cord
Power Adapter
5 Year Warranty
