Sensors
2 x 8K sensors.
Left eye and right eye.
CONTACT US
WE WANT TO HEAR FROM YOU
Please feel free to Email: mediatitanstech@gmail.com or Phone: (03) 9021 2521 or send us a message here. Please allow one business day to respond.
INQUIRIES
- Description
- Camera Features
- Controls
- Connections
- Computer Interface
- Standards
- Media
- Network Management
- Software
- Shipping details
- Reviews
Description
Blackmagic URSA Cine Immersive is the world’s first camera system for capturing Apple Immersive Video for Apple Vision Pro. The dual 8K sensors deliver 8160 x 7200 resolution per eye with pixel level synchronization and an incredible 16 stops of dynamic range. The custom lens system is designed exclusively for URSA Cine Immersive’s large format imaging sensor. Blackmagic URSA Cine Immersive comes with a massive 8TB of removable high performance media storage built in and also includes high speed 10G Ethernet and WiFi for fast media upload and syncing to Blackmagic Cloud!
Camera Features
Effective Sensor Size
23.66 mm x 20.88 mm each.
Pixel Pitch
2.9 microns.
Lens
Fixed focal length, 180°+ field of view,stereo lens pair.
Dynamic Range
16 Stops.
Shooting Formats
8160 x 7200 x 2 (stereo immersive)
Frame Rates
Project frame rates of 23.98, 24, 25, 29.97, 30, 50,59.94, 60 and 90 fps supported.
High Speed Frame Rates
8K stereo immersive up to 90 fps.
Built in ND Filters
Button activated ND filters with clear, 2‑stop, 4‑stop, 6‑stop and 8‑stop IR ND filters.
Iris Control
Fixed iris.
Screens
2 x Monitoring Screens.
1 x Camera Status Screen.
Monitoring Screen Dimensions
5 inch.
Monitoring Screen Resolution
1920px x 1080px.
Monitoring Screen Brightness
1500 nits.
Monitoring Screen Type
LCD capacitive touchscreen.
Monitoring Options
Left Eye, Right Eye, Punch In.
Metadata Support
Discrete left and right eye optical calibration metadata. Automatic recording of camera settings and slate data such as project, scene number, take and special notes.
Controls
Touchscreen menus on 5 inch screen. Push buttons for other controls. 7 assignable shortcut keys plus 3 assignable shortcut keys on PYXIS Monitor. Fischer connector for remote run/stop.
Timecode Clock
Highly accurate timecode clock. Less than 1 frame drift every 8 hours.
Connections
Total Video Outputs
2
SDI Rates
1.5G, 3G, 6G, 12G.
Analog Audio Inputs
2 x XLR analog switchable between mic, line and AES audio. Phantom power support.
Analog Audio Outputs
1 x 3.5mm headphone jack.
Reference Inputs
Tri-Sync/Black Burst and Timecode.
USB-C Monitor Outputs
2 x USB-C side monitor ports support URSA Cine EVF, PYXIS Monitor or DisplayPort monitors.
Computer Interface
2 x USB-C side expansion ports for camera accessories.
Software updates using side USB-C closer to rear.
Ethernet
1 x 10Gb/s RJ‑45 connector supporting 10/100/1000/10G BASE-T for SMB file sharing, Web Media Management, Blackmagic Cloud uploads, camera control and streaming.
Audio
Microphone
Integrated stereo microphone.
Built in Speaker
1 x mono speaker.
Standards
SD Video Standards
None
HD Video Standards
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
SDI Compliance
SMPTE 292M, SMPTE 424 Level B, SMPTE 2081-1, SMPTE 2082-1
SDI Audio Sampling
48 kHz and 24 bit.
Media
Media
1 x Blackmagic Media Module.
Media Format
Blackmagic
Supported Codecs
Codecs
Blackmagic RAW Constant Bitrate 5:1
Blackmagic RAW Constant Bitrate 8:1
Blackmagic RAW Constant Bitrate 12:1
Blackmagic RAW Constant Bitrate 18:1
Blackmagic RAW Constant Quality Q0
Blackmagic RAW Constant Quality Q1
Blackmagic RAW Constant Quality Q3
Blackmagic RAW Constant Quality Q5
Control
External Control
Blackmagic PYXIS Monitor can trigger record plus camera functions assigned to the F1, F2, F3. External Camera Control supported using REST API over Ethernet or WiFi. Blackmagic iPad control and Bluetooth control supported. Blackmagic Zoom Demand for controlling camera.
Network Management
NTP
Network time protocol support allows you to sync the time on your camera, whenever connected to a network with any NTP server of your choice.
FTP
Download files from any drive attached to your camera using FTP.
Web Media Manager
Using a browser connected over Ethernet, web media manager allows you to access, browse, download and delete files from any drive connected to the camera.
SMB
File sharing using SMB.
Storage Features
Storage Type
1 x Blackmagic Media Module 8TB.
Storage Rates
Storage rates based on 90 frames per second.
8K Stereo Immersive
8160 x 7200 x 2
Blackmagic RAW 5:1 - 3,202 MB/s
Blackmagic RAW 8:1 - 2,001 MB/s
Blackmagic RAW 12:1 - 1,334 MB/s
Blackmagic RAW 18:1 - 890 MB/s
Blackmagic RAW Q0 - 1,601 to 5,337 MB/s
Blackmagic RAW Q1 - 1,334 to 4,574 MB/s
Blackmagic RAW Q3 - 801 to 4,003 MB/s
Blackmagic RAW Q5 - 534 to 2,287 MB/s
Constant Quality Rates are: Q0 10:1 - 3:1, Q1 12:1 - 3.5:1, Q3 20:1 - 4:1, Q5 30:1 - 7:1
Actual storage rates are dependent on image subject matter.
Recording Formats
Blackmagic RAW 5:1, 8:1, 12:1, 18:1, Q0, Q1, Q3 and Q5 at 8160 x 7200 resolution for each eye.
Software
Software Included
URSA Cine Blackmagic OS
DaVinci Resolve Studio for Mac and Windows including activation key
Blackmagic Camera Setup
Blackmagic RAW Player
Blackmagic RAW QuickLook Plugin
Blackmagic RAW SDK
